Spindle Observation System

for Nikon Eclipse Ti2, Ti a TE2000 and Diaphot 200/300 Series

Nikon Advanced Modulation Contrast (NAMC) observation
  • Manufacturer: Nikon
  • Ref No.: MXA22164 SET st
  • Availability: 4 weeks
  • Price without VAT: 9 980,00 €
  • Price including VAT: 12 075,80 €
9 980,00 €

The image of the spindle can be seen with the naked eye in the eyepieces, for documentation it is possible to use any (even existing) camera, which has a true color display. We will be happy to send you an offer for a camera on request. The spindle can be colored blue or red, depending on the orientation toward the polarized light. At the same time, the color change from red to blue as the spindle rotates indicates that it is indeed a spindle, not an artifact. Petri dishes with a 0.17 mm glass bottom must be used for observation. Below is a diagram of the arrangement of individual elements of the system.  Heated plates can be used either with glass (ideally 0.5 mm thick) or metal with a hole

Consists of:

MXA22164

TS2R-C-SO Spindle Observation System
Slider and Condenser Module

1

AD-SLIDER-…

Adapter for pro slider for   Ti2/Ti/TE2000

1









MEN51942

TC-C-DICP DIC pull-out polariser
Not necessary for Ti2 microscopes, but simplifies module handling and allows easy and safe ejection of the polarizer from the optical path
Required for Ti and TE2000 microscopes

1

AD-CMOD

Adapter for Condenser Module
Not necessary in case of use of TC-C-DICP polariser.

1
